Combination Compressor is consist of screw compressor, air dryer, air tank and filters. It combines all you need for compressor system and easy for use. Just Plug in and run!
Technical parameters of tank mounted PM VSD screw air compressor with air dryer
|
Model
|
Power(kw）
|
Capacity
(m3/min)
|
Pressure(Mpa）
|
Dimension(mm)
|
Weight(kg)
|
Pipe Diameter
|
Tank
|
|
DSPM-10ATD
|
7.5
|
1.1
|
8
|
1580*650*1500
|
340
|
G 3/4
|
360L
|
|
DSPM-15ATD
|
11
|
1.6
|
8
|
1580*650*1500
|
440
|
G 3/4
|
360L
|
|
DSPM-20ATD
|
15
|
2.2
|
8
|
1580*650*1500
|
450
|
G 3/4
|
360L
|
|
DSPM-25ATD
|
18.5
|
2.9
|
8
|
2100*900*1900
|
870
|
G 1
|
510L
|
|
DSPM-30ATD
|
22
|
3.5
|
8
|
2100*900*1900
|
920
|
G 1
|
510L
|
Technical parameters of tank mounted screw air compressor
|
Model
|
Power
(kw）
|
Capacity
(m3/min)
|
Pressure(Mpa）
|
Dimension(mm)
|
Weight(kg)
|
Pipe Diameter
|
Tank
|
|
DSR-10ATD
|
7.5
|
1.1
|
8
|
1580*650*1500
|
340
|
G 3/4
|
360L
|
|
DSR-15ATD
|
11
|
1.6
|
8
|
1580*650*1500
|
440
|
G 3/4
|
360L
|
|
DSR-20ATD
|
15
|
2.2
|
8
|
1580*650*1500
|
450
|
G 3/4
|
360L
|
|
DSR-25ATD
|
18.5
|
2.9
|
8
|
2100*900*1900
|
870
|
G 1
|
510L
|
|
DSR-30ATD
|
22
|
3.5
|
8
|
2100*900*1900
|
920
|
G 1
|
510L
|
Combination Compressor is consist of screw compressor, air dryer, air tank and filters. It combines all you need for compressor system and easy for use. Just Plug in and run!
Technical parameters of tank mounted PM VSD screw air compressor with air dryer
Technical parameters of tank mounted screw air compressor
